JF-3A Digital Oxygen Index Meter

Construction Materials-Other Building Materials
Expand

Product Content

Category
Construction Materials-Other Building Materials

JF-3A Digital Oxygen Index Tester

Tip: The JF-3A Digital Oxygen Index Tester differs from the JF-3 Digital Oxygen Index Tester: The digital oxygen index tester produced by Beijing Xinsheng Zhuorui has a temperature control instrument to control the temperature, while other parameters are consistent with the JF-3 Digital Oxygen Index Tester.

I. Application Scope: The digital oxygen index tester produced by Beijing Xinsheng Zhuorui is suitable for testing the combustion performance of materials such as plastics, rubber, fibers, foam plastics, sheets, films, and textiles.

Beijing Xinsheng Zhuorui Instrument Equipment Co., Ltd.
Phone: 18513498889
QQ: 2028696743
Phone: 010-58418090
Fax: 010-58043777
Website: www.bjkji.com
Address: No. 158, Science Park, Haidian District, Beijing
Main Products: Oxygen Index Tester / Horizontal and Vertical Combustion Tester / Building Material Combustibility Testing Furnace / Building Material Non-Combustibility Testing Furnace / Building Material Smoke Density Tester / Large Plate Fireproof Coating Tester / Initial Drying Crack Resistance Testing Device / Electronic Testing Machine / High and Low Temperature Testing Chamber / Low Temperature Freeze-Thaw Testing Chamber / Constant Temperature and Humidity Chamber / Cigarette Paper Smoldering Performance Tester, Hardness Tester, Thickness Gauge, Concrete Instruments, Cement Testing Instruments, Mortar Testing Instruments, Slurry Testing Instruments, Geotechnical Testing Instruments, Asphalt Testing Instruments, Highway Aggregate Instruments, Waterproof Material Instruments, Highway Rock Instruments, Pavement Testing Instruments, Pressure Testing Machine Curing Room Instruments and Laboratory Consumables, etc.

II. Main Technical Parameters:

1. The digital oxygen index tester produced by Beijing Xinsheng Zhuorui uses imported oxygen sensors, with digital display of oxygen concentration requiring no calculations, providing higher accuracy, range 0—

2. Comes with a temperature control instrument to control temperature.

3. Digital resolution: ±0.1%

4. Measurement accuracy: Grade 0.4

5. Flow adjustment range: 0-10L/min (60-600L/h)

6. Response time: <5S

7. Combustion tube: Inner diameter ≥75㎜ height 400mm

8. Gas flow rate in the combustion tube: 40mm ± 10mm/s

9. Pressure gauge accuracy 2.5 grade, resolution: 0.01MPa

10. Flowmeter: 1-15L/min (60-900L/H) adjustable, test environment: ambient temperature: room temperature to 40℃; relative humidity: ≤70%;

11. Input pressure: 0.2-0.3MPa

12. Working pressure: nitrogen 0.1-0.15Mpa oxygen 0.1-0.15Mpa Oxygen / nitrogen mixed gas inlet: includes pressure regulator, flow control valve, gas filter, and mixing chamber.

13. The digital oxygen index tester produced by Beijing Xinsheng Zhuorui can be used for soft and hard plastics, textiles, fire doors, etc.

14. Propane (butane) ignition system, flame length 5mm-60mm adjustable

15. Gas: industrial nitrogen, oxygen, purity > 99% ; (user to prepare).

16. Power requirements: AC220 (+10% )V, 50Hz

17. Maximum power consumption: 50W

18. Igniter: has a metal tube with an inner diameter of Φ2 ±1mm nozzle, can be inserted into the combustion tube to ignite the sample, flame length: 16 ±4mm , size adjustable

19. Self-supporting material sample clamp: can be fixed at the central position of the combustion tube and can vertically clamp the sample.

20. Non-self-supporting material sample clamp: can simultaneously fix both vertical edges of the sample on the frame.

III. Chassis and Structural Components:

1. Control box: The digital oxygen index tester produced by Beijing Xinsheng Zhuorui is processed and formed by CNC machining, electrostatic spraying, beautiful, rust-proof, and corrosion-resistant. The control part is separated from the testing part.

2. Combustion tube: High-temperature quartz glass tube (inner diameter ￠75mm, length 300mm) outlet inner diameter: φ40mm

4. Mixer: The digital oxygen index tester produced by Beijing Xinsheng Zhuorui uses glass beads to uniformly mix oxygen and nitrogen. (Bead φ4.5mm filling height 95mm, one bag)

5. Sample clamp: The digital oxygen index tester produced by Beijing Xinsheng Zhuorui has a self-supporting clamp that can vertically clamp the sample; (optional non-self-supporting sample rack), two sets of sample clamps meet different testing requirements; the sample clamp is plug-in type, making it easier to place samples and clamps.

7. Comes standard with a spare glass tube to prevent accidental damage and meet uninterrupted testing needs; the long rod igniter tail pipe hole diameter is￠2 ±1mm, igniter flame length (5-50）mm can be adjusted freely

V. The design standards for the digital oxygen index tester produced by Beijing Xinsheng Zhuorui: GB/T 2406.2-2009 GB/T 2406.1-2008

Complies with standards: ASTM D 2863, ISO 4589-2, NES 714 GB/T 5454 GB/T 10707 GB/T 8924-2005 GB/T 16581-1996 NB/SH/T 0815-2010 TB/T 2919-1998 IEC 61144-1992 ISO 15705-2002 ISO 4589-2-1996
