PVC drip edge, also known as hawk beak netting, is a measure to prevent rainwater from flowing down the wall into the balcony or onto the glass. Typically, it is installed at the junction between the bottom surface and the outer wall, about 1-2 cm away from the corner. With the drip edge in place, water is diverted and will not flow inward. It is suitable for parts of construction projects that require water diversion, such as protruding window sills, window heads, including window tops that do not protrude, awnings, balconies, coping of parapets, and belt lines that protrude from the outer wall. All these areas should have a drip edge installed.
Common specifications for PVC drip edge:
1．PVCdrip edge width:25mm x 30mm
2．PVCdrip edge length:2m ―2.5m
3．PVCdrip edge mesh width:100mm x 100mm
4．PVCdrip edge packaging:150pieces per box, also available as per customer requirements.
Product Features:
In order to prevent rainwater backflow, which can damage buildings, most modern buildings use insulation boards to create the hawk beak shape. The dimensions cannot be standardized, which is not aesthetically pleasing and complicates the process. Ensuring quality is quite difficult, and it also generates a large amount of foam waste. To address these issues, our company has researched and produced the drip edge. This drip edge can solve the aforementioned problems.
