HaoTian Brand High-Temperature Protective Sleeving Manufacturer Direct Sales

Product Name: Haotian Brand High-Temperature Protective Sleeve

Specification: Inner diameter 6.5mm-130mm, each length 15M, 20M, 100m (customized), no joints.

Packaging: 20M/roll (3 rolls/box)

Long-term operating temperature: 300-500℃ Instantaneous can reach: 1300℃

Note: Ningguo City, Anhui Province, is a domestic research and production base for thermal insulation sleeves! Quality has been recognized by customers at home and abroad.

Haotian Brand High-Temperature Protective Sleeve (Coated Type) is widely used in high-temperature areas of industries such as steel, automotive, shipbuilding, aerospace, metallurgy, electromechanics, petrochemicals, chemicals, military, national defense, scientific research, and other industries. It is suitable for cables in heating areas, fluid pipelines, rolling mill cables, oil pipes, saw edge cables, generator sets, electrical voltage equipment, large buildings, hydraulic systems, automotive wiring harnesses, exhaust pipes, and more.

High-Temperature Sleeve Manufacturing Process:

Haotian Brand High-Temperature Protective Sleeve is woven from special alkali-free quartz fiber yarn, coated with organic high-temperature silicone resin, and processed through high-temperature vulcanization. It possesses:flame retardant, thermal insulation, heat preservation, electrical resistance, softness, and corrosion resistance.

Haotian Brand High-Temperature Protective Sleeve can provide long-term, reliable insulation protection in high-temperature environments of 300℃, preventing radiation and heat waves. This sleeve can also be made into a split type (removable) using flame-retardant imported Velcro and special fireproof high-temperature thread according to customer requirements, making it convenient for future inspection. Different forming methods greatly facilitate the maintenance and emergency repair needs of various specifications and conditions on the production site. Installation is simple, convenient, and time-saving; just slide it on and secure both ends with “clamps” or wrap them with high-temperature resistant tape to fix it.

Dielectric strength: Depending on the wall thickness, withstand voltage can reach from 10KV to 30KV.
Color: Red, black, yellow, blue, gray, etc. Generally in iron red, but can be made in other colors as per customer requirements.

Anhui Haotian Brand High-Temperature Protective Sleeve uses environmentally friendly materials, is dust-free, non-toxic to the human body, and does not cause any allergic reactions. The structure is more scientific, from the outer layer’s temperature resistance, wear resistance, flame retardance, thermal insulation to the interlayer’s waterproof, oil and gas resistance, insulation, and to the inner layer’s temperature resistance, heat preservation, and flame retardance, greatly improving the product’s protective effect in high-temperature areas, extending the continuous working time of high-temperature equipment, achieving energy saving and consumption reduction, and lowering the operation and maintenance costs for enterprises.

Wall thickness: (generally from 1mm to 5mm) the ability to resist molten steel or other high-temperature liquids: exceptionally excellent! Special wall thickness (according to customer requirements) can be specially customized.

Inner diameter (mm): Φ6.5mm--Φ100mm Inner diameter tolerance (mm) wall thickness and tolerance (mm) m/roll.
