APVCComposite Tile
APVC composite wave tiles have advantages such as durable color (unchanged for ten years), UV resistance (long lifespan), easy cleaning, lightweight, self-waterproof, toughness, thermal insulation, sound insulation, corrosion resistance, wind and earthquake resistance, hail resistance, stain resistance, green and environmentally friendly, fireproof, insulation, and easy installation, providing advanced solutions for long-term use in corrosive factories, heavy acid rain areas, and rooftops.
Product Characteristics:Durable Color
APVC composite wave tiles exhibit extraordinary durability in natural environments, maintaining their color stability even when exposed to harsh conditions such as UV rays, humidity, heat, and cold for long periods. This overcomes the fading issue commonly associated with pure PVC tiles. Tests conducted in regions with intense sunlight, such as Arizona and Florida in the USA, have proven that color change after ten years is ensured to be ΔE≤5.
Excellent Corrosion Resistance
APVC composite wave tiles can withstand corrosion from various chemical substances, including acids, alkalis, and salts, for long periods. Experimental results show no chemical reaction after 24 hours of immersion in salt, alkali, and acids below 60%. They are particularly suitable for areas with frequent acid rain, corrosive factories, and coastal regions, making them an ideal alternative to color steel tiles!
Excellent Weather Resistance
The surface material of APVC composite wave tiles is co-extruded with ultra-weather-resistant resin, making it one of the best weather-resistant engineering plastics internationally. This ensures that the product maintains its color and physical mechanical properties even under prolonged exposure to harsh outdoor conditions.
Strong Fire Resistance
APVC composite wave tiles have a fire performance rating of ≥B1, classifying them as flame-retardant materials.
Good Sound Insulation
Tests have proven that APVC composite wave tiles have excellent noise absorption capabilities when subjected to external noises from heavy rain and strong winds, reducing noise by over 30dB compared to color steel plates. The foam wave tiles exhibit even better sound insulation effects.
Excellent Thermal Insulation
The thermal conductivity coefficient of APVC composite wave tiles is 0.325w/m.k, which is about 1/310 of clay tiles, 1/5 of cement tiles, and 1/2000 of 0.5mm thick color steel tiles. Therefore, even without considering adding insulation layers, the thermal insulation performance of APVC composite wave tiles can still achieve the expected effect!
Outstanding Load Resistance
APVC composite wave tiles possess good load-bearing capacity. In colder regions, even with snow accumulation on the roof for extended periods, the surface will not suffer damage or cracking. Tests have shown that 2.0mm APVC composite wave tiles can support 100kg with a support spacing of 800mm without cracking or damage.
Excellent Waterproof Performance
The high weather-resistant resin used in APVC composite wave tiles is dense and does not absorb water, eliminating the problem of micro-pore water infiltration. Additionally, proprietary patented accessories effectively resolve water leakage issues at screw holes.
Impact Resistance and Low-Temperature Performance
APVC composite wave tiles have strong external impact resistance. Tests show that a 1-kilogram steel ball dropped from a height of 3 meters does not cause any cracks, and their impact resistance at low temperatures is also significant.
Excellent Insulation Properties
APVC composite wave tiles are insulating products that remain intact even when subjected to accidental discharge, especially ensuring safety in lightning-prone areas compared to metal tiles. They are also anti-static materials, which help reduce dust accumulation on the surface.
Green and Environmentally Friendly
APVC composite wave tiles contain no asbestos or radioactive elements and can be recycled, fully complying with green and environmental protection requirements.
Quick Installation
APVC composite wave tiles are lightweight, and the complete set of installation accessories makes them very easy to assemble and disassemble, resulting in high installation efficiency.
Product Specifications
Thickness (mm): 1.5, 2.0, 2.5, 3.0
Colors: Blue, Gray, Dark Green, Bright Red, Brick Red
Rongsu APVC Corrosion-Resistant Composite Wave Board Structural Features:
1. Dual waterproof performance: The edge wave is 54% higher than the 820 board type, and one edge wave structure has a groove to prevent water from exceeding the wave height and flowing out from the hidden groove, providing dual waterproof functionality.
2. With patented technology accessories, the waterproof, wind-resistant, and corrosion-resistant performance is improved by three levels. This structure employs fully sealed screw heads to address corrosion of screw heads, aging of waterproof rubber rings, and leakage at screw holes; waterproof rubber rings beneath the pressure plate prevent water from seeping into screw holes; and the enlarged screw fixing positions enhance typhoon resistance.
Three protections: edge wave, hidden groove, and screw hole waterproofing
Two durability features: screw heads and waterproof rubber rings do not contact air or rainwater, ensuring durability.
One resistance feature: typhoon resistance can reach level 10
