Flextron AD18.5-M22*1.5 Nylon Quick Connector Processing, Flextron AD18.5-M22*1.5 Nylon Quick Connector Processing, Flextron AD18.5-M22*1.5 Nylon Quick Connector Processing
Baoji Flextron Machinery Co., Ltd., 18700704284, http://www.bj-flex.com
Nylon quick connectors, nylon push-in connectors, corrugated nylon connectors, plastic corrugated pipe connectors, cable protection pipe connectors, corrugated pipe ends
Nylon push-in connectors are divided into 90 degree elbows and straight connectors, and installation does not require tools, making it convenient for installation and disassembly, greatly reducing the time required for installation and disassembly. Connections are simple, quick, reliable, and safe; just apply slight force to insert the hose into the connector to complete the connection. After insertion, applying force again will secure the hose and achieve a certain level of protection. For disassembly, simply press the internal locking buckle on the connector's end face, and with slight force, the hose can be pulled out, completing the disassembly. Flextron plastic corrugated pipes and quick connectors are widely used in various fields due to their simplicity, speed, reliability, and safety. However, suitable hoses and connectors should be selected for different occasions based on requirements such as temperature, corrosion resistance, flame resistance, protection level, and flexibility. The size of different wire harnesses and cables can be determined according to the outer diameter of the wire harness that needs to be installed inside the hose, and a general recommendation of 10% extra space is suggested. Some connector selections also depend on the thread specifications of the equipment or steel pipes they connect to. These are the general product selection standards; in special circumstances, users are advised to consult professionals. Flextron welcomes customers to call for inquiries, and we will provide you with professional answers and products.
Flextron AD18.5-M22*1.5 Nylon Quick Connector Processing
Wiring Hose Connector Series
Product Introduction:
1. Metal Hose Connectors
Metal hose connectors are made of materials such as zinc alloy, stainless steel, or copper-nickel plated through die casting, with surface finishes including polished, galvanized, frosted, and chrome-plated. They are tightly structured, free of air holes, and have high strength. They connect reliably with metal hoses, featuring good sealing, shock resistance, corrosion resistance, waterproofing, dustproofing, and aesthetic appearance. They are widely used in machinery, rail transit, power plants, automation projects, oil equipment, and other fields. They can connect metal hoses with equipment or enclosures with openings, equipment with internal threads, external threaded steel pipes, or non-threaded steel pipes according to installation requirements. Various non-standard or other materials of metal hose connectors can also be customized.
Junction Box Connection Connectors: for connecting metal hoses to junction boxes (boxes), with waterproof types; Straight connector junctions: for connecting metal hoses to each other, with waterproof types; No-thread connection connectors: for connecting metal hoses to steel conduits or steel pipes; Mixed connection connectors: for connecting metal hoses to threaded steel pipes, with waterproof types at 90 degrees and waterproof types at 45 degrees; Grounding clamps: for grounding metal hoses.
1、DPJ External Thread Connector, this metal connector is end-connected, used to connect metal hoses to straight connectors on enclosures;
2、DKJ Ferrule Type, this metal connector is a ferrule type, used to connect metal hoses to non-threaded steel pipes;
3、DGJ Self-locking Type, this metal connector is self-locking, used to connect metal hoses to non-threaded steel pipes or non-threaded equipment outlets;
4、90 Degree Elbow, after connection forms a90 degree angle with the enclosure, aesthetically pleasing, tightly structured, and high strength.
5、45 Degree Elbow, after connection forms a45 degree angle with the enclosure, aesthetically pleasing, tightly structured, and high strength.
6、Y-shaped Three-way Connector, T-shaped three-way metal connector, can connect three metal hoses or three non-threaded steel pipes, or can connect metal hoses and steel pipes, various non-standard metal hose connectors and special metal connectors can be customized.
7、Stainless Steel Hose Connectors are made of standard stainless steel casting, tightly structured, free of air holes, and high strength. They are reliable when connected to stainless steel hoses and have an aesthetically pleasing appearance.
8、Metal Hose Plastic Connectors, this type of connector is mainly used for connecting metal hoses to external threaded equipment or steel pipes, made of nylon or plastic, used for general power distribution protection, cost-effective, lightweight, and has weaker pressure resistance.
9、Locking Cable Metal Hose Connectors are equipped with locking cable connectors on ordinary metal hose connectors, preventing cable loosening. The internal locking buckle is specially designed for the main body, and installation and disassembly require only plugging and unplugging without tools, greatly reducing installation time. The clamping range for the cable is large, with strong tensile strength. The product has acid and alkali resistance, chemical resistance, and resistance to general solvents, as well as waterproof and dustproof features. It can be widely used in various fields for outlet holes.
10、External Locking Hose Connectors are designed to lock metal hoses, mainly used for connecting explosion-proof hoses, with very strong tensile capability. Due to the excellent quality of explosion-proof metal hoses, their own weight is very heavy, plus the traction of internal cables, the downward pulling force on vertically suspended explosion-proof hoses is very large. Therefore, this type of locking hose connector can effectively solve these problems, with two clamps externally set, locking the hose via screws.
2. Nylon Hose Connectors
Nylon hose connectors are made of nylon 6 material, mainly for connecting flame-retardant corrugated hoses with equipment, featuring good temperature resistance, corrosion resistance, wear resistance, and high mechanical strength. They are primarily applicable in various industries, including machine tools, instruments, automation control, robotics, subway vehicles, locomotives, and more.
1、Nylon push-in connectors are divided into90 degree elbows and straight connectors, and installation does not require tools, making it convenient for installation and disassembly, greatly reducing the time required for installation and disassembly. Connections are simple, quick, reliable, and safe; just apply slight force to insert the hose into the connector to complete the connection. After insertion, applying force again will secure the hose and achieve a certain level of protection. For disassembly, simply press the internal locking buckle on the connector's end face, and with slight force, the hose can be pulled out, completing the disassembly. Flextron plastic corrugated pipes and quick connectors are widely used in various fields due to their simplicity, speed, reliability, and safety. However, suitable hoses and connectors should be selected for different occasions based on requirements such as temperature, corrosion resistance, flame resistance, protection level, and flexibility. The size of different wire harnesses and cables can be determined according to the outer diameter of the wire harness that needs to be installed inside the hose, and a general recommendation of 10% extra space is suggested. Some connector selections also depend on the thread specifications of the equipment or steel pipes they connect to. These are the general product selection standards; in special circumstances, users are advised to consult professionals. Flextron welcomes customers to call for inquiries, and we will provide you with professional answers and products.
2. Openable nylon connectors are mainly used for connecting open nylon hoses. This type of connector introduces advanced technology from Germany, effectively solving the issue in electrical maintenance where some cable lines cannot be disassembled but require replacing the external protective layer. The open corrugated pipe is itself split; during installation, simply open the hose, insert the cable, and close it. The openable connectors used with the open corrugated pipe are mainly for connecting the open corrugated pipe with the distribution box; they can be opened to insert the hose and close it before connecting to the equipment, saving the loss caused by disassembling the cable, making it simple and practical.
3、Openable nylon three-way connectors are divided intoT type three-way andY type three-way, mainly used for connecting corrugated pipes to each other, for connection and protection at wire crossing nodes. The openable nylon three-way connectors adopt a locking connection method, which can be easily opened for replacement and maintenance. They are suitable for machine tools, machinery manufacturing, power equipment, electrical control systems, automotive wiring harnesses, and engineering installations.
Openable connector systems do not require tools, making installation and disassembly convenient, greatly reducing the time required for installation and disassembly. Connections are simple, quick, reliable, and safe; just open the connector, insert the pipe, and fasten the buckle to complete the installation, achieving a certain level of protection. For disassembly, simply force open the locking buckle, and the hose can be easily removed, completing the disassembly. Flextron plastic corrugated pipes and openable connectors are widely used in various fields due to their simplicity, speed, reliability, and safety. However, suitable hoses and connectors should be selected for different occasions based on requirements such as temperature, corrosion resistance, flame resistance, protection level, and flexibility. The size of different wire harnesses and cables can be determined according to the outer diameter of the wire harness that needs to be installed inside the hose, and a general recommendation of 10% extra space is suggested. Some connector selections also depend on the thread specifications of the equipment or steel pipes they connect to. These are the general product selection standards; in special circumstances, users are advised to consult professionals. Flextron welcomes customers to call for inquiries, and we will provide you with professional answers and products.
Main Products: Metal and non-metal hoses, stainless steel hoses, P3 type stainless steel snake skin pipes, P4 type stainless steel wiring pipes, single hook stainless steel snake skin pipes, double buckle stainless steel pull-resistant hoses, stainless steel single buckle hoses, stainless steel double hook corrugated pipes, stainless steel instrument tubing, stainless steel optical fiber cable protection pipes, stainless steel flexible conduit pipes, stainless steel flexible metal hoses, plastic-coated metal hoses, external PVC metal hoses, flame-retardant plastic-coated corrugated pipes, single buckle stainless steel plastic-coated hoses, double buckle stainless steel flat-coated pipes, galvanized single buckle plastic-coated hoses, double buckle galvanized plastic-coated hoses, pull-resistant double buckle plastic-coated hoses, cotton thread anti-horizontal pipes, single hook embedded cotton thread flat-coated plastic hoses, galvanized metal hose connectors, waterproof metal hose connectors, stainless steel connectors, copper-nickel plated connectors, external thread metal hose connectors, end-type snake skin pipe connectors, external female metal hose connectors, internal female stainless steel connectors, internal snake skin pipe connectors, ferrule type metal hose connectors, three-column top screw connectors, three-claw locks, self-locking snake skin pipe connectors, self-locking metal hose connectors, 45 degree elbows, 90 degree elbows, waterproof cable connectors, nylon cable fixing heads, nylon cable connectors, stainless steel gland heads, stainless steel cable connectors, explosion-proof glands, copper-nickel cable connectors, copper-nickel gland heads, cable glands, plastic corrugated pipes, PE corrugated pipes, PP corrugated pipes, PA corrugated pipes, open nylon hoses, single opening plastic corrugated pipes, open wiring hoses, double-layer open nylon hoses, double opening corrugated pipes, twin corrugated hoses, openable nylon connectors, open corrugated pipe connectors, locking cable hose connectors, stainless steel clamping cable connectors, stainless steel cable sealing heads, metal hose cable connectors, waterproof hose connectors, wiring boxes, distribution boxes, corrugated pipe fastening clamps, wire and cable clips, corrugated pipe fixed bases
