FLATON Openable T-shaped Three-Way Connector Manufacturer Sales
The openable connector system produced by FLATON requires no tools, making installation and disassembly convenient and significantly reducing installation and disassembly time. The connection is simple, quick, reliable, and safe; just open the connector, insert the pipe, and tighten the buckle to complete the installation, achieving a certain level of protection. For disassembly, simply force open the locking buckle to easily remove the hose and complete the disassembly. FLATON's plastic corrugated pipes and openable connectors are used in various fields due to their simplicity, speed, reliability, and safety. However, different occasions require the selection of appropriate hoses and connectors based on requirements such as temperature, corrosion resistance, flame retardant grade, protection level, and flexibility, among others, to choose hoses made from different materials. The specific hose size can be determined based on the outer diameter of the harness that needs to be installed inside the hose, generally recommending a 10% surplus space. Some connector selections also need to be determined based on the thread specifications of the equipment or steel pipes they connect to. These are the general selection standards for the products; for special situations, users are advised to consult professionals. FLATON welcomes customers to call for consultation, and we will provide you with professional answers and products.
Material: Nylon PA
Temperature Range: -40℃~115℃, short-term up to150℃
Color: Black
Flame Retardant Grade: V0
Properties: Oil-resistant, acid and alkali resistant, waterproof, UV resistant, insulated, halogen-free, flame retardant.
Application Occasions: Machine tools, machinery manufacturing, power equipment, electrical control systems, automotive wiring harnesses, engineering installation
Usage Method: Y-shaped three-way connector, after opening, connect to the corrugated pipe, assemble the pipeline, and directly close it.
|
Specification |
Hose Specification AD1 |
Hose Specification AD2 |
Hose SpecificationAD3 |
LengthA （mm） |
WidthB （mm） |
Packaging Quantity （Only/Package） |
|
7-7-7 |
AD7.0 |
AD7.0 |
AD7.0 |
25.6 |
27.4 |
100 |
|
10-7-7 |
AD10.0 |
AD7.0 |
AD7.0 |
25.6 |
28.2 |
100 |
|
10-7-10 |
AD10.0 |
AD7.0 |
AD10.0 |
25.6 |
31.3 |
100 |
|
10-10-10 |
AD10.0 |
AD10.0 |
AD10.0 |
30.8 |
33.5 |
100 |
|
13-10-13 |
AD13.0 |
AD10.0 |
AD13.0 |
32.5 |
36.6 |
100 |
|
13-13-13 |
AD13.0 |
AD13.0 |
AD13.0 |
32.5 |
36.4 |
100 |
|
16-10-10 |
AD15.8 |
AD10.0 |
AD10.0 |
32.5 |
37.4 |
100 |
|
16-10-13 |
AD15.8 |
AD10.0 |
AD13.0 |
32.5 |
37.4 |
100 |
|
16-13-13 |
AD15.8 |
AD10.0 |
AD13.0 |
32.5 |
36.6 |
100 |
|
16-13-16 |
AD15.8 |
AD13.0 |
AD15.8 |
38.0 |
39.6 |
100 |
|
16-16-16 |
AD15.8 |
AD15.8 |
AD15.8 |
40.0 |
43.0 |
100 |
|
21-13-13 |
AD21.2 |
AD13.0 |
AD13.0 |
33.0 |
40.4 |
100 |
|
21-13-16 |
AD21.2 |
AD13.0 |
AD15.8 |
33.0 |
40.4 |
100 |
|
21-13-21 |
AD21.2 |
AD13.0 |
AD21.2 |
37.0 |
46.1 |
100 |
|
21-16-13 |
AD21.2 |
AD15.8 |
AD13.0 |
36.0 |
49.0 |
100 |
|
21-16-16 |
AD21.2 |
AD15.8 |
AD15.8 |
37.0 |
42.0 |
100 |
|
21-16-21 |
AD21.2 |
AD15.8 |
AD21.2 |
39.0 |
47.7 |
100 |
|
21-21-10 |
AD21.2 |
AD21.2 |
AD10.0 |
41.0 |
41.6 |
100 |
|
21-21-13 |
AD21.2 |
AD21.2 |
AD13.0 |
38.0 |
41.5 |
100 |
|
21-21-21 |
AD21.2 |
AD21.2 |
AD21.2 |
39.0 |
47.7 |
100 |
