Precision Monitoring: Utilizes grating ruler and pressure sensor for position and pressure monitoring, improving pressing accuracy. Position Accuracy: The main cylinder position repeatability reaches ±0.01mm, effectively controlling waste caused by machine tool accuracy issues.
Pressure Accuracy: The main cylinder pressure repeatability reaches ±3%, effectively controlling waste caused by machine tool accuracy issues.
Energy Saving: High-power motor meets the process requirements of high speed and high pressure, and the use of servo motor drive achieves optimal energy saving; energy saving can reach 30-50%.
Silent Operation: The servo motor drive system meets the varying speed and pressure requirements of different processes, and operates more smoothly and quietly.
Main Cylinder Design: Made from a single forging and precision ground, ensuring high reliability under high pressure conditions.
Machine Structure: The body is made from high-quality steel plate, cut and welded as a whole, and annealed. Finite element analysis ensures minimal elastic deformation under maximum pressure. The slider adopts a four-corner eight-face guide rail design, with strong vibration resistance and anti-eccentric load capacity, ensuring stable and precise operation.
