Foleton Metric Nylon Cable Gland

Flextong Metric Nylon Cable Gland Manufacturer Direct Sales in Xi'an Nylon Cable Gland / Nylon Cable Fixed Head Thread Specifications: Metric Threads, German Threads, American Threads, British Threads. Product Material: The nut, body, clamping claw, and sealing head are made of environmentally friendly nylon PA6; the gasket is made of aging-resistant silicone rubber, and the clamping ring is made of oil-resistant rubber. Flame Retardant Rating: UL94V-2. Protection Level: Within the specified clamping range, and using waterproof gaskets and clamping rings to tighten the sealing head, achieving IP67. Color Variants: Gray-white, black. Usage Method: First, pass the body through the machine panel, then tighten and fix it with a nut, thread the cable through the sealing head, and tighten the sealing head to secure it. Working Temperature: Static -40°C to 85°C. Product Features: The integrated design of the clamping claw and clamping ring, combined with the sealing head assembly, saves time and is convenient; it has a large clamping range, strong tensile strength, and is waterproof, dustproof, resistant to salt, acid and alkali, alcohol, oil, grease, and general solvents. It is used for fixing and protecting the cable outlet and sealing against dust and water. More Choices: Various clamping rings are also available, and when used outdoors in high-demand environments, rubber needs to be replaced with aging-resistant silicone rubber material. Cable joints are essential accessories for connecting cables and equipment, commonly referred to in the industry as "cable glands, cable fixed heads, cable locks, cable terminal joints." Cable joints have been widely used in Germany and are now popular in China. According to different usage environments, cable joints can be classified by material into nylon cable joints, nickel-plated copper cable joints, and stainless steel cable joints. Unless there are special requirements, most customers choose nylon cable joints due to their lower cost; some customers opt for nickel-plated copper cable joints. In desert or cold climate environments, stainless steel cable joints are generally required due to their strong corrosion resistance and relatively long lifespan. In specific usage scenarios, there are also differences in the structure of cable joints, such as shielded cable joints, armored cable joints, and explosion-proof cable joints. For specific selections, please contact our company, Baoji Flextong Machinery Co., Ltd. Regarding cable joint selection tips: 1. The outer diameter of the cable must be within the clamping range of the selected cable joint. 2. The thread size of the cable joint is very important; its thread specifications must match the threaded hole of the connected device. 3. When purchasing cable joints, consider whether it is necessary to have matching locking nuts. Baoji Flextong Machinery Co., Ltd. (www.flextong.com) is located in the ancient city of Baoji, Shaanxi, China. Baoji, known as "Yongcheng" in ancient times, is praised as the "Hometown of Emperor Yan and the Land of Bronze." Baoji is a key industrial base in the People's Republic of China, and after more than 60 years of efforts, it has developed into a major heavy industrial base, characterized by large and medium-sized state-owned enterprises and defense military enterprises. Baoji Flextong Machinery Co., Ltd. is a leading supplier of products such as flexible hoses, hose joints, plastic-coated metal flexible hoses, stainless steel hoses, nylon corrugated hoses, nylon hose joints, waterproof cable joints, cable glands, cable fixed heads, wiring boxes, and hose mounting clamps. The Flextong brand's double-lock stainless steel flexible conduit (SUS Interlocked Flexible Conduit), stainless steel conduit fittings (SUS Flexible Conduit Fittings), nickel-plated brass conduit fittings (Nickel Plated Brass Flexible Conduit Fittings), malleable iron conduit fittings (Malleable Iron Flexible Conduit Fittings), malleable iron conduit bodies (Malleable Iron Conduit Body), and conduit clips (Conduit Clips) are exported to Australia, New Zealand, India, Turkey, the UK, and other regions. The products produced by Baoji Flextong Machinery Co., Ltd. are widely used in fields such as railway locomotives, automation, machinery manufacturing, wind power, and instrumentation.
