EZ98-150 Portable Electronic Water Level Meter (150 meters)

Construction Materials-Other Building Materials
Expand

Product Content

Category
Construction Materials-Other Building Materials
EZ98-150 Portable Electric Water Level Meter (150 meters) The portable electric water level meter is suitable for hydrological observation holes, geological drill holes, water wells, reservoir dams, and direct measurements of rivers, lakes, and seas in geological, mining, and hydrology departments. It replaces the currently commonly used primitive and outdated methods of measuring water levels such as measuring tapes, measuring clocks, electric wires, and multimeters. The portable electric water level meter consists of a measuring line, probe, water level detector, reel, bracket, conductive mechanism, handle, and carrying bag. Its main features include small size, light weight, low cost, and convenience for carrying. Technical Features: 1. Maximum measurement depth: 150m 2. Maximum measurement error: ≤±0.1% (±0.1cm/100m), meeting the Class III water level meter accuracy standard specified by international ISO. 3. Probe diameter: 14mm, sensitivity area of the probe ≤±5mm. 4. Repeat measurement accuracy: ≤±10mm. 5. Measuring line technical conditions: outer diameter 2.0, 7/0.25 galvanized steel core, high-density polyethylene insulation, breaking tensile strength ≥25 kgf. 6. Water level detector sensitivity: external ground resistance ≥500KΩ. 7. Water level detector power consumption: ≤15mA. 8. Water level detector power supply: 6F22, 9V stack battery. 9. Operating environment: -20℃ to +40℃, relative humidity 85%.
