Brief Description:During the operation of the extrusion sheet machine, some minor malfunctions may occur, and jamming is one of the more common faults. When a jam occurs, the rollers cannot extrude the raw material into shape, and the dry roller compactor does not rotate.
Extrusion sheet main machineDuring the usage, some minor malfunctions may occur, and clogging is one of the more common machine failures. When clogging happens, the rollers cannot extrude the raw material into shape, and the dry roller compactor does not rotate. Clogging not only affects the production speed but also impacts the equipment's lifespan. The reasons affecting clogging are as follows:
1. Steam quality hazards
The ideal production and manufacturing standards in the processing of granules are: suitable raw material moisture, high-quality steam, and sufficient time for conditioning. Proper use of dry saturated steam for granulation can effectively increase the output and quality of the granules produced by the dry roller compactor.
2. The hazards of the gap between the die and the roller
The gap between the die and roller is too large, causing the material layer between them to be excessively thick and unevenly distributed, which can easily lead to roller misalignment. If the extrusion pressure of the die and roller on the raw material is lower than the resistance from the friction inside the die cavity, the raw material cannot be extruded, leading to a machine jam. To reduce the occurrence of jams, it is necessary to adjust the gap between the die and roller during production. The ideal adjustment is when the roller and the die ring are in a state where they seem to touch but do not, and appear to rotate but do not.
3. The adverse effects of actual aging treatment
The quality of the granules must be excellent to meet the competitive demands of the sales market. The effectiveness of the pre-treatment of raw materials before granulation is very important, as it directly affects the output and quality of the granules from the dry roller compactor, especially the water stability of special aquatic feed, which is a key indicator.
Below, we will introduce extrusionExtrusion host for sheet materialsStartup Operation Method:
Before starting the sheet extruder, first preheat for about 40 to 50 minutes. Heat until you can pull the motor's V-belt by hand and feel it move smoothly and effortlessly; then pull it continuously in the normal working direction 8 to 10 times. Then continue heating for about 10 more minutes before starting the machine, but keep heating because continuous heat supplementation is needed for normal production; adjust the temperature according to the properties of different plastics.
2. During normal operation, the machine temperature needs to remain stable and should not fluctuate. The temperature around the vent holes up to the head of the machine should be maintained at around 200°C (for propylene and ethylene materials).
3. The feeding must be uniform and sufficient. The machine's intake speed should match the feed supply speed. Otherwise, it will affect the quality and output of the pellets.
4. When shutting down, the main power supply to the host must be completely disconnected.
