Keeping a clean road surface in the work and production environment is very important for the safety of employees and machinery. In order to maintain workplace safety, whether temporary or permanent, is a proactive way to reduce risks. Equally important is the safety of cables and wires themselves. Using our rubber cable trough board, cable bridge board, stage bridge board, performance cable trough, PVC cable cover board, rubber cable threading trough is a simple and effective way to achieve safety in offices, workshops, event sites, employees, factories and equipment, and the general public in public places. Cable and hose protection are built with rigidity, adhering to government-regulated work environments and occupational health and safety regulations.
Product Description:
1.Advanced polyurethane (UV cured) process
2.Special bottom grip design rubber stage performance cable trough board, no need to damage the ground for installation
3.High insulation level, breakdown voltage 7500v, load bearing 65 tons
4.High compressive load bearing, suitable for heavy trucks, forklifts, generators, broadcasting vehicles, container trucks
5.Durable, proprietary Durathane polyurethane pouring molding
Shanghai Yilan Traffic Facilities Co., Ltd. has developed rubber cable trough boards, which have been inspected by the National Technical Supervision Bureau and issued inspection report certificates, ensuring the safety of customers using rubber stage performance cable trough boards. In addition, the bottom has a strong adhesion design, can be placed and installed at will, without the need for bolts to damage the ground or use tools, and can also prevent running and displacement, effectively protecting the safe use of cables
Exhibition Hall Cable Bridge Stage Cable Bridge Rental Stage Cable Bridge
Our company has developed a series of cable trough products so far:
Type A straight board:
Medium two groove specifications: 1000*450*70mm groove diameter: 50*50mm weight: 13 kg
Two groove specifications: 800*300*45mm groove diameter: 30*25mm weight: 7 kg
Medium two groove specifications: 800*430*65mm groove diameter: 50*50mm weight: 12.5 kg
Large two groove specifications: 660*580*105mm groove diameter: 90*90mm weight: 19 kg
Three groove specifications: 1000*345*50mm groove diameter: 30*30mm weight: 12 kg
Three groove specifications: 800*430*50mm groove diameter: 30*30mm weight: 12 kg
Large three groove specifications: 800*520*85mm groove diameter: 65*65mm weight: 14.5 kg
Four groove specifications: 800*500*65mm groove diameter: 50*50mm weight: 16.5 kg
Five groove specifications: 800*500*50mm groove diameter: 30*30mm weight: 12.5 kg
Type A all straight boards can be equipped with 90° corners and three-way corners.
Type B straight board:
3 groove 1000mm*310mm*55mm (3 groove) aperture: 35x35mm
