Electric Hoist Handle Cable, Crane Control Dedicated Cable RVV(2G)

Electric Hoist Handle Cable, Crane Control Special Cable RVV(2G) **Product Summary**: Self-supporting steel wire cable - Yichu wire and cable **Product Description** Application Range: As a connection and control cable for electric hoists, suitable for various electrical installations in dry or humid indoor environments. Due to its special flexible design, it is also suitable for installation or fixed laying under stress-free, forced-guided, left and right non-continuous motion conditions. (Not for use as elevator cable for vertical lifting.) **Product Features:** Jute rope is added between the cable cores for load-bearing, and a layer of non-woven fabric is wrapped between the core wires and the sheath for cushioning. For ultra-high lengths, two load-bearing steel wires are available (breaking tensile strength up to 10.4KN, height up to 150 meters). The modified PVC sheath offers better tensile and tear strength than general rubber materials while maintaining flexibility. Better product performance, safer to use. **Cable Structure:** Conductor: Multi-strand ultra-fine twisted oxygen-free copper wire, in accordance with VDE0295 CLASS 5 standard. Insulation: Special mixed PVC insulation. Colors: Colorful color numbers, in accordance with JJS C3306 standard. Black numbers and white numbering, in accordance with IEC227 standard. (Please specify if it contains a yellow-green grounding wire.) Inner Liner: Special non-woven fabric wrap for cushioning. Steel Wire: One or two non-twisting self-supporting steel wires, bearing the tension generated during operation. Sheath: Special mixed PVC sheath, black (RAL9005). **Detailed Parameters:** Rated Voltage: Less than or equal to 1.5mm: 300/500V Greater than 1.5mm: 450/750V Test Voltage: Less than or equal to 1.5mm: 2500V Greater than 1.5mm: 3000V Operating Temperature Range: -15℃ to +70℃ Bending Radius: 20 times the outer diameter of the cable. Yichu Cable products are insured by Ping An Insurance Company of China. Main products: Drag chain cables, elevator traveling cables, crane cables, servo cables, overhead traveling cables, computer cables, photovoltaic cables, shielded cables, CE cables, UL cables, national standard CCC cables, communication coaxial cables, cables for reel equipment, electrical installation cables, and security cables, etc. Shanghai Yichu Wire and Cable is a professional manufacturer of wires and cables. After more than a decade of development, our wires and cables meet international standards and have received unanimous praise from domestic and foreign customers. Sales engineer Mr. Zhu is dedicated to providing customers with cost-effective cables. Technical support: 18817228506 QQ 350701807 Phone: 021-68182666-640 Fax: 021-68182790
