Product Name: Haotian Brand High-Temperature Resistant Cable Protective Sleeve

Specifications: Inner diameter 6.5mm-130mm, length per piece 15M, 20M, 100m (custom required), no joint ends.

Packaging: 20M/roll (3 rolls/box)

Long-term operating temperature: 300-500℃ Instantaneous can reach: 1300℃

Note: Ningguo City, Anhui Province is a domestic research and production base for thermal insulation sleeves! Quality has been recognized by customers at home and abroad.

Haotian Brand (coating type) high-temperature resistant cable protective sleeves are widely used in: steel, automotive, shipbuilding, aerospace, metallurgy, electromechanical, petrochemical, chemical, military, defense, scientific research, and other industries' high-temperature areas. Heating area cables, fluid pipelines, rolling mill cables, oil pipes, edge-cutting cables, generator sets, electrical voltage equipment, large buildings, hydraulic systems, automotive wiring harnesses, exhaust pipes, and other industries.

High-temperature sleeve manufacturing process:

Haotian Brand high-temperature resistant cable protective sleeves are woven from special alkali-free quartz fiber yarn and coated with organic high-temperature resistant silicone resin, then subjected to high-temperature vulcanization. They have:flame retardant, thermal insulation, heat preservation, electrical resistance, soft corrosion resistance, and other properties.

Haotian Brand high-temperature resistant cable protective sleeves can provide long-term, reliable insulation protection in high-temperature environments of 300℃, preventing radiation and heat waves. This sleeve can also be made into a split type (removable) with flame-retardant imported Velcro and special fire-resistant high-temperature threads according to customer requirements, facilitating future inspections. Different forming methods greatly facilitate maintenance and emergency repair needs of various specifications and conditions on the production site. Installation is simple and time-saving; it only requires placing it over the cables and securing both ends with "clamps," or wrapping both ends with high-temperature resistant tape for fastening.

Dielectric strength: Depending on the wall thickness, withstand voltage can reach from 10KV to 30KV.
Color: Red, Black, Yellow, Blue, Gray, etc. Generally iron red, but can also be made into other colors upon customer request.

The Haotian Brand high-temperature resistant cable protective sleeves are made entirely from environmentally friendly materials, dust-free, non-toxic to the human body, and will not cause any allergic reactions. The structure is more scientific, from the outer layer’s heat resistance, abrasion resistance, flame retardancy, and thermal insulation, to the middle layer’s waterproof, oil/gas resistance, insulation, and down to the inner layer’s heat resistance, heat preservation, and flame retardancy, greatly enhancing the product's protective effect in high-temperature areas, extending the continuous working time of high-temperature equipment, achieving energy savings and reducing the operating and maintenance costs for enterprises.

Wall thickness: (Generally from 1mm to 5mm) capability to resist molten steel or other high-temperature liquids: extremely outstanding! Special wall thickness (according to customer requirements) can be specially customized.

Inner diameter (mm): Φ6.5mm--Φ100mm Inner diameter tolerance (mm), wall thickness and tolerance (mm) meters/roll.
