Detailed information of WLF-1 flow valve with scale:
Input pressure: ≤0.6Mpa Output pressure: ≤0.4Mpa
Output flow rate: 0-1000ml/min Input and output pressure drop: ≥0.05MpaTaper Shank Twist Drill Variable Speed Oscillator Digital Temperature Control Electric Heating Sleeve
Flow stability: ≤1.5% FL/15min Installation aperture: Ф12.5mm
Input and output pipe diameter: Ф3.0mm Special requirements 0-1600-3000ML/min Customized separately
Application: Widely used for automatic adjustment of gas flow stability, such as gas chromatography, atomic absorption, flame photometry, biochemical instruments, petrochemical and environmental protection instruments, etc.Hundred-level Laminar Flow Ward Extended Twist Drill Sulfurimeter
Instructions for use: The flow valve usually has 1 inlet and 2 outlets, one of the outlets can be connected to a pressure gauge or left unplugged. There is an arrow at the inlet. The size of the output flow rate is adjusted by rotating the knob counterclockwise to increase the output flow rate, and vice versa, rotating clockwise to decrease the output flow rate. Precision valves should be adjusted slowly. To achieve a good flow stability effect, a stabilizing valve is generally added before the flow valve. Ring Stiffness Tester Crude Oil Water Content Meter ME204 LMI Milton Roy
