Home > Products list > Raw Plastic Materials > Delrin® 500T NC010
Delrin® 500T NC010
￥ 32000.00/Ton
Engineering Plastic-POM
Expand
Product Content
Category
Engineering Plastic-POM
Form
Granules
Colour
Color Categories
Plastic grades
500T
Factory owners
DowDuPont
The source
DuPont
Delrin® 500T NC010
Acetaldehyde resin
DuPont Mobility & Materials
Product Description:
Toughened medium viscosity acetal homopolymer
  • Processing method
  • Materials
  • Visual Search
  • Curve Data
  • Place of Purchase
Overview
Material Status
  • Already Commercialized: Currently Valid
UL Yellow Card 1
  • E530507-104597283
Search UL Yellow Card
  • DuPont Mobility & Materials
  • Dering®
Supply Area
  • North America
  • Africa and the Middle East
  • Latin America
  • Europe
  • Asia-Pacific region
additives
  • Impact Modifier
  • Mold release

RoHS Compliance
  • Contact the manufacturer
Automotive requirements
  • Chrysler MS-DB-100 CPN2939
  • Chrysler MS-DB-100 CPN2979 Color: Refer to the color marked on the drawing
  • Ford WSK-M4D681-A2
  • Genetically Modified POM.016 Type

multi-point data
  • Isothermal Stress and Strain (ISO 11403)
  • Relationship between secant modulus and strain (ISO 11403)
  • Relationship between shear stress and shear rate (ISO 11403)
  • Specific volume versus temperature (ISO 11403)
  • Tensile Modulus vs. Temperature (ISO 11403)
  • Viscosity and shear rate (ISO 11403)
Component Identification Code （ISO 11469)
  • >POM-I<
Resin ID （ISO 1043)
  • POM-I type
Physical properties
Rated Value
System of Units
Test Method
Density
1.38
g/cm³
 ISO 1183 certification
Melt flow rate (melt flow index) （190°C/2.16 kg）
12
g/10 min
 International Organization for Standardization 1133
Melt Volume Flow Rate (MVR) （190°C/2.16 kg）
10
cm³/10 min
 International Organization for Standardization 1133
shrinkage rate
     International Organization for Standardization 294-4
vertical
1.6
%

flow
1.5
%

Water absorption rate
     International Organization for Standardization (ISO 62)
24 hours, 23°C
0.30
%

Saturated, 23°C, 2.00 mm
0.82
%

Equilibrium, 23°C, 2.00 mm, 50% RH
0.21
%

Hardness
Rated Value
System of Units
Test Method
Rockwell hardness
     International Organization for Standardization 2039-2
M Weighing Scale
79


R Weighing
117


Ball Pressure Hardness （H 961/30）
155
MPa of
 International Organization for Standardization 2039-1
Mechanical properties
Rated Value
System of Units
Test Method
Tensile Modulus
2300
MPa of
 ISO 527-1 certification
Tensile stressYield
55.0
MPa of
 International Organization for Standardization 527-2
Tensile strainYield
18
%
 International Organization for Standardization 527-2
Nominal tensile fracture strain
35
%
 International Organization for Standardization 527-2
Tensile Creep Modulus
     International Organization for Standardization 899-1
1 hour
2300
MPa of

1000 hours
1200
MPa的 MPa's

Flexural Modulus
2100
MPa of
 International Organization for Standardization 178
Bending stress(3.5% strain)
60.0
MPa of
 International Organization for Standardization 178
Poisson's ratio
0.39
