Cross-linked Polyethylene Insulated Power Cable
Construction Materials-Other Building Materials
Expand
Product Content
Category
Construction Materials-Other Building Materials
**Cross-linked Polyethylene Insulated Power Cable** 1. **Product Purpose:** This product is suitable for power lines with rated voltage (U0/U) of 3.6/6 to 26/35KV, used for power transmission and distribution. 2. **Product Standard:** GB12706-91 Rated voltage of 35KV and below for copper core and aluminum core plastic insulated power cables. 3. **Product Usage Characteristics** (1) The cable can be laid without preheating when the ambient temperature is not lower than 0℃. There are no restrictions on the laying drop of the cable. (2) The long-term allowable working temperature of the cable core must not exceed the following regulations: For cables with PVC outer sheath, it is 90℃; for cables with polyethylene outer sheath, it is 80℃. (3) During a short circuit of the cable core (***lasting up to 5 seconds), the temperature must not exceed 250℃. (4) The minimum bending radius when laying the cable is as follows: Ø Single-core cable: 20(d+D)±5%; Ø Three-core cable: 15(d+D)±5%. Where D is the actual outer diameter of the cable, and d is the actual outer diameter of the conductor. 4. **Product Models, Names, and Usage Scope**
Model Name Usage Scope
Copper Core Aluminum Core
YJV YJLV Cross-linked Polyethylene Insulated PVC Sheathed Power Cable Fixed installation in the air, indoors, cable trenches, tunnels, or underground
YJY JYLY Cross-linked Polyethylene Insulated Polyethylene Sheathed Power Cable Fixed installation indoors, in cable trenches, tunnels, or underground
YJV22 YJLV22 Cross-linked Polyethylene Insulated Steel Tape Armored PVC Sheathed Power Cable Fixed installation in places subjected to external pressure
YJV23 YJLV23 Cross-linked Polyethylene Insulated Steel Tape Armored Polyethylene Sheathed Power Cable Fixed installation in places frequently subjected to external forces
YJV32 YJLV32 Cross-linked Polyethylene Insulated Fine Steel Wire Armored PVC Sheathed Power Cable Fixed installation in places required to withstand tensile forces
YJV33 YJLV33 Cross-linked Polyethylene Insulated Fine Steel Wire Armored Polyethylene Sheathed Power Cable Fixed installation in places required to withstand tensile forces
YJV42 JYLV42 Cross-linked Polyethylene Insulated Coarse Steel Wire Armored PVC Sheathed Power Cable Fixed installation underwater, in vertical shafts, or in places required to withstand tensile forces
YJV43 YJLV43 Cross-linked Polyethylene Insulated Coarse Steel Wire Armored Polyethylene Sheathed Power Cable Fixed installation in places required to withstand greater tensile forces
**Note:** One or two single-core cables are not allowed to be laid in iron pipes. 5. **Production Scope**
Model Number of Cores Rated Voltage U0/U(KV)
3.6/6; 6/6 6/10; 8.7/10 12/20; 18/20 21/35; 26/35
Nominal Cross-section of Conductive Core (mm²)
YJLV
YJV
YJLY
YJY
1 25-500 25-500 35-500 50-300
YJLV32
YJV32
YJLY32
JYY32
1 25-500 25-500 35-500 50-300
YJLV42
YJV42
YJLV43
YJV43
1 25-500 25-500 35-500 50-300
YJLV
YJV
YJLY
YJY
3 25-300 25-300 35-300 -
YJLV22
YJV22
YJLV23
YJV23
3 25-300 25-300 35-300 -
YJLV32
YJV32
YJLV33
YJV33
3 25-300 25-300 35-300 -
YJLV42
YJV42
YJLV43
YJV43
3 25-300 25-300 35-150 -
