CPVC Converging Three-Way Ball Valve - Advantages of Plastic Three-Way Ball Valve Q41F-10V

Construction Materials-Other Building Materials
Expand

Product Content

Category
Construction Materials-Other Building Materials
CPVC converging three-way ball valve advantages: Converging three-way ball valve - CPVC flange three-way ball valve NSF certified, the converging three-way ball valve meets drinking water standards, has low switch torque, made from pure materials without the addition of CaCO3, contains UV powder for strong UV resistance, L-shaped three-way ball valve is pressure tested before leaving the factory, can be installed with pneumatic or electric actuators, material description: PVC, CPVC, Clear PVC, PP, PVDF, sizes: 1/2'' - 4''; 20mm - 110mm; DN15 - DN100, standards: ANSI, DIN, JIS, CNS, L-shaped three-way ball valve connections: socket, threaded (NPT, PT, BSPF), fusion, welding, double-sealed ball valve working pressure: 150 PSI, operating temperature: PVC (0~55℃); CPVC & PP (0~95℃), handle colors for the converging three-way ball valve: red, blue, green, orange; body colors: PVC (dark gray), CPVC (light gray), PP (beige), Clear PVC (transparent), PVDF (ivory). (1) Extrusion: High molecular weight PVDF has good melt strength and can be processed into films, sheets, pipes, rods, and electrical insulation sleeves through extrusion. Depending on the equipment used and the shape of the product being processed, the temperature should be controlled between 210~290 degrees Celsius, and the molding temperature should be controlled between 180~240 degrees Celsius. The temperature must be strictly controlled and should not exceed the melting temperature for an extended period. General screw extrusion machines can be used for extrusion molding. (2) Injection molding: Low molecular weight PVDF has a high melt flow rate and can be processed using injection molding methods, typically using a general-purpose injection machine. However, the barrel plunger, nozzle, and other components must be made of corrosion-resistant Ni-based alloys. (3) Casting: Casting molding uses dimethyl as the solvent to prepare a PVDF solution with a solid content of 20%, which is cast onto aluminum foil. After heat melting at 205~315 degrees Celsius, it is rapidly cooled with water to form a continuous tough film with a thickness of 0.05~0.075mm. (4) Molding: Typically, PVDF pellets are preheated in an oven or preheating furnace at a temperature of 215~235 degrees Celsius. The preheated material is then placed into a preheated mold at 180~195 degrees Celsius, and pressure is applied at 14MPa, maintaining pressure for a time depending on the required melting and flow. Thick-walled products must be maintained under pressure and cooled to below 90 degrees Celsius before demolding to avoid vacuum bubbles or deformation. (5) Transfer molding: Generally, the material is first plasticized using an extruder, then conveyed to a storage cylinder. A plunger pump injects the material from the storage cylinder into the mold, maintaining pressure and cooling. Whether molding or transfer molding, this method is mainly used to produce larger volume and thicker wall products. (6) Other processing methods: PVDF can also be processed using impregnation, co-extrusion, and other processing techniques. Shanghai Huanqi Plastic Pipe Co., Ltd. Name: Wang Zhigang Company Phone: 021-57562878 Company Fax: 021-57562676 Mobile: 15900400720 Email: twhq29@163.com Company Website: http://www.hqpvc.com
