Chemical Grade Plastic Diaphragm Valve PVDF Corrosion Resistant Plastic Diaphragm Valve Plastic Diaphragm

Construction Materials-Other Building Materials
Expand

Product Content

Category
Construction Materials-Other Building Materials
Applicable to:
1. Industrial and fluid pipeline systems (acid and alkali liquid transport in metal processing, electroplating plants, pharmaceutical and refining plants; bleaching, dyeing, and acid-alkali liquid pipelines in textile and leather factories; residue and slurry pipelines in mining, metallurgy, and fertilizer factories; deionized water flow treatment systems in semiconductor manufacturing plants; factory water supply, distribution, and cooling water pipeline systems)
2. Food processing (sea and fresh water distribution pipelines in fish farms and fish hatcheries; brine pipeline systems in packaging factories; pipelines for dairy products, canned goods, and beverages)
3. General usage scenarios (pipelines for swimming pools and hot springs; methane recovery pipeline systems in landfills; groundwater drainage pipelines; air conditioning system pipelines; drinking water distribution pipeline systems)
4. Pulp and paper (pipeline systems for aluminum and caustic soda solutions; chlorine dioxide, chlorine, and caustic soda pipelines in chemical plants)
5. Water supply and sewage treatment (chlorine injection systems; pipelines for aluminum chloride and ferric chloride solutions; sedimentation tanks and filtration pipelines; reclaimed water treatment pipelines)
6. Irrigation (golf courses, greenhouses, agriculture, residential and commercial)
7. Non-usable scenarios (not suitable for compressed air or gas applications)
FRPP Enhanced polypropylene Working temperature -14°C to 90°C
CPVC Chlorinated polyvinyl chloride Working temperature -20°C to 95°C
PVDF Polyvinylidene fluoride Working temperature -40°C to 140°C
UPVC Rigid polyvinyl chloride Working temperature -10°C to 70°C
Scope of use and structural features
Plastic diaphragm valves are suitable for the transport and interception of corrosive media and for flow adjustment, with a working temperature range of -14°C to 140°C depending on the material.
The flow components of plastic diaphragm valves are assembled from RPP or PVDF injection molded parts, providing excellent corrosion resistance.
The sealing diaphragm of plastic diaphragm valves is made from F46 or PFA, with a burst resistance of ≥12000 cycles, offering corrosion resistance comparable to F4.
Plastic diaphragm valves utilize a screw lift structure, allowing for high torque and good stability during operation.
Installation and use
When connecting the flanges at both ends to the pipeline, bolts should be tightened evenly to prevent flange deformation, which could cause leaks.
Rotate the handle clockwise to close and counterclockwise to open.
The degree of opening can be determined by the position of the indicator.
