Product Features:
1. Tough, insulated, ultra-high pressure resistance (can support 65 tons)
2. Suitable for all outdoor weather, waterproof, lightning-proof, moisture-proof, flame-retardant
3. Slip-resistant textured surface
4. All-around protection for various cables and communication data lines
5. Unique design, no ground damage required for installation
6. Durable, slip-resistant textured surface
7. Easy to install, convenient to move, simple and practical structural design
8. Unique selection of elbow, tee, and reducing fittings
9.1 Hole, 2 holes, 3 holes, 4 holes, 5 holes diverse designs, fully applicable to industries such as exhibitions, performances, workshops, electricity, communications, and military.
A Class Straight Plates:
Medium Double Slot Specifications: 1000*450*70mm Slot Diameter: 50*50mm Weight: 13 kg
Double Slot Specifications: 800*300*45mm Slot Diameter: 30*25mm Weight: 7 kg
Medium Double Slot Specifications: 800*430*65mm Slot Diameter: 50*50mm Weight: 12.5 kg
Large Double Slot Specifications: 660*580*105mm Slot Diameter: 90*90mm Weight: 19 kg
Triple Slot Specifications: 1000*345*50mm Slot Diameter: 30*30mm Weight: 12 kg
Triple Slot Specifications: 800*430*50mm Slot Diameter: 30*30mm Weight: 12 kg
Large Triple Slot Specifications: 800*520*85mm Slot Diameter: 65*65mm Weight: 14.5 kg
Quadruple Slot Specifications: 800*500*65mm Slot Diameter: 50*50mm Weight: 16.5 kg
Quintuple Slot Specifications: 800*500*50mm Slot Diameter: 30*30mm Weight: 12.5 kg
A Class Straight Plates can be configured with 90° corners and tee corners.
Cable Rubber Speed Bump, Highway-Specific Speed Bump
B Class Straight Plates:
Small Double Slot Specifications: 1000*250*50mm Slot Diameter: 32*35mm Weight: 7 kg
Triple Line Slot Specifications: 1000*300*50mm Slot Diameter: 35*32mm Weight: 9 kg
Large Double Slot Specifications: 900*580*90mm Slot Diameter: 80*95mm Weight: 22 kg
Triple Line Slot Specifications: 900*500*85mm Slot Diameter: 70*65mm Weight: 15 kg
Quadruple Line Slot Specifications: 900*500*60mm Slot Diameter: 40*45mm Weight: 15 kg
Quintuple Line Slot Specifications: 900*500*50mm Slot Diameter: 30*40mm Weight: 14 kg
Medium Single Slot Specifications: 1000*260*70mm Slot Diameter: 50*70mm Weight: 8.5 kg
Large Single Slot Specifications: 1000*580*120mm Slot Diameter: 125*100mm Weight: 22 kg
The above are some of the cable trays produced by our company. The appropriate tray should be chosen based on the diameter and quantity of the cables. For more details, please consult the sales department manager.
