1: Product Material: The nut, basic body, and the tightening nut part are made of nylon PA66 (flame retardant rating UL 94V-2), while the gasket and clamping ring are made of rubber or EPDM weather-resistant rubber.
2: Protection Level: IP68-5 pressure (rotary type, with O-ring sealing).
3: Operating Temperature: Static -40°C to 100°C, or can withstand up to 120°C for a short time; Dynamic -21°C to 80°C, or can withstand up to 100°C for a short time.
4: Color Variety: Gray, black, other colors can be customized.
5: Product Features: Special design of the clamping claws and clamping ring, tightening nut with elastic buckle, large clamping range for cables, strong tensile strength; can be waterproof, dustproof, resistant to salt, weak acids, alcohol, oil, grease, and general solvents.
6: Application Range: Used in electrical electronic control equipment, military industry, petroleum, chemical industry, explosion-proof, textile, medical, aviation communication, machine tool manufacturing, measurement control technology, instrument manufacturing, and many other industries for plastic-coated soft hoses, cables, and wire joints.
Features:
1. The clamping ring is specially designed to have strong tensile strength without damaging the cables.
2. There is no need to disassemble the fixed head; the cable can be directly inserted and tightened, saving time and convenience.
Usage: For fixing cables in general mechanical control boxes, distribution cables, machines, electrical appliances, etc.
Material: Nylon plastic, flame retardant VO grade (UL94).
Sealing Material: Nitrile rubber (NBR).
Protection Level: IP68 (when using O-ring).
Temperature Range: Static -40°C to 100°C, short-term up to 120°C; Dynamic -20°C to 80°C, short-term up to 100°C.
Features: Can effectively clamp cables and achieve waterproofing.
PG German Thread.
