Technical FeaturesSpeed Adjustable Multi-purpose Oscillator
1. The purification device is microcomputer controlled, easy to operate, and stable and reliable in performance. Users only need to press the (Start) button to purify ordinary argon gas into high-purity argon, eliminating the gas impurity caused by human operational errors in manual and semi-automatic purification machines, which can lead to analysis failures in the spectrometer. With the development of this fully automatic purification device, there will no longer be issues of gas impurity due to human error, allowing users to feel more at ease and ensuring more stable and reliable data analysis from the spectrometer.Woven Bag Tension Tester Eco-friendly Electric Heating Jacket FE30K
2. This purification device consists of several internal structures. The main function of the catalytic tower is to treat O2, CO+CO2, and some non-polar molecules in the argon gas. Secondly, the adsorption tower (dual structure) primarily deals with H2O and impurities in the argon gas. Once the adsorbent becomes saturated, it can be regenerated to restore its activity for long-term use, with regeneration accomplished through a self-purge process using its own gas, eliminating the need for vacuum and avoiding flammable and explosive gases, thus ensuring safety. Thirdly, a high-efficiency filtration device filters and purifies the gas in layers, resulting in high-purity gas output. The internal system employs high-purity gas dedicated leak-proof stainless steel corrugated pipe valves, electrochemically polished stainless steel pipelines, and stainless steel fittings and connectors to prevent secondary gas contamination.Modular Air Supply Unit Plastic Bending Testing Machine
3. The dual structure allows one group to operate while the other group is on standby for regeneration, and both operation and regeneration occur automatically, enabling long-term continuous gas supply.
Main Technical Indicators
1. Input Raw Gas
This purification machine allows for an oxygen content in the raw argon gas of ≤3000ppm and water ≤1000ppm (i.e., dew point below -20℃). Generally, bottled pure argon can meet these requirements.Cylindrical Shank Twist Drill High-Pressure Reaction Kettle Vertical Flow Purification Workbench
2. Output Pure Gas (≥99.999%)
The maximum output capacity of pure gas is 4m³/h
Impurity content in pure gas: O2≤0.4ppm
H2O≤2ppm i.e., dew point ≤-70℃
C oxides ≤0.1ppm
S, P oxides ≤0.1ppm
Dust particle count (≥0.3µm) 3-5 per liter, i.e., Class 100
