Raw Material Composition
1. Aluminum Alloy Lined Plastic PP-R Composite Pipe: 6063-T5 aluminum pipe; imported inner lining PP-R raw material (e.g., Korea Oil Chemical 2400)2. Aluminum Alloy Lined Plastic PE-RT Composite Pipe: 6063-T5 aluminum pipe; imported inner lining PE-RT raw material (e.g., DX800)
3. Aluminum Alloy Lined Plastic PB Composite Pipe: 6063-T5 aluminum pipe; imported inner lining PB raw material
4. Aluminum Alloy Lined Plastic PE Composite Pipe: 6063-T5 aluminum pipe; imported inner lining PE raw material
Detailed Features
Luxurious Appearance — The aluminum alloy lined plastic composite pipe has an aesthetically pleasing appearance with a metallic luster. It overcomes the shortcomings of plastic pipes deforming and bending due to thermal expansion. The weight of aluminum alloy lined plastic composite pipes is only about one-fifth of other metal pipes, effectively reducing the load on buildings. It is suitable for main water supply and heating pipes in constructions such as residential and commercial buildings, hotels, and living communities, enhancing the overall quality and grade of the buildings.Higher Heat Resistance — Due to the protection of the outer metal layer (aluminum layer) of the aluminum alloy lined plastic composite pipe, it eliminates the risk of elastic creep caused by heat and pressure on the inner lining layer, and there will be no occurrence of plastic creep. Therefore, aluminum alloy lined plastic composite pipes can withstand higher temperatures than pure plastic pipes, and their service life is also longer.
50 Years Maintenance-Free — The inner and outer layer materials used in aluminum alloy lined plastic composite pipes are all domestic materials, and under normal usage conditions, the pipe system will maintain its aesthetic and robustness without incurring additional costs for anti-rust and anti-corrosion. The unique inner lining layer of aluminum alloy lined plastic composite pipes forms an integral part with the outer aluminum pipe after thermal fusion connection, and the good processing technology at the joint prevents the risk of pipe bursting and installation contamination, overcoming the damage to pipes caused by rust in general metal pipes.
Green and Environmentally Friendly — The inner lining materials of aluminum alloy lined plastic composite pipes, such as PP-R/PE-RT/PB/PE, do not react chemically with ions in water or with any chemicals that may come into contact with them. For example, the PP-R raw material consists only of carbon and hydrogen elements, with no harmful elements, making it sanitary and non-toxic, corrosion-resistant and non-scaling. It qualifies as a green and environmentally friendly product, suitable for pure water drinking systems, liquid beverage transportation systems, liquid pharmaceutical transportation systems, and more. During the production, construction, and use of aluminum alloy lined plastic composite pipes, there is no pollution to the environment.
Aluminum alloy lined plastic composite pipes have a wide range of applications. Depending on the different inner lining materials, they also cover application fields such as: sand and gravel transportation systems in mines and islands; water, gas, and oil transportation systems in oil fields; natural gas transportation systems in residential communities, etc.
Precautions
1. The manufacturing processing technology of aluminum alloy lined plastic composite pipes has high requirements for manufacturers. Users should pay attention to quality and be cautious of low-priced products when selecting.
2. The installation of aluminum alloy lined plastic composite pipes requires high standards; during construction, it is necessary to strictly follow the Runshuo Pipeline Technology Construction Manual and conduct standardized construction.
3. The applications of aluminum alloy lined plastic composite pipes vary due to different inner lining materials; users should understand and consult clearly when selecting.
